Brand Name : | OTA |
Model Number : | OTQX-1000 |
Certification : | CE, ISO |
Price : | USD2350-USD5980 |
Payment Terms : | L/C, T/T |
Supply Ability : | 100SETS/MONTH |
Delivery Time : | 10-15 DAYS |
Wide Span Cnc Metal Carbon Steel Rust Removing Fiber Laser Cleaning
Machine
Product descriptions:
Laser cleaning machines can quickly remove various contaminants such as oil stains, rust, paint, scale, etc. by irradiating the surface of an object with a high-energy laser beam. This cleaning method will not cause damage to the surface of the object, so it is especially suitable for cleaning precious or fragile items.
Secondly, the laser cleaning machine also has the function of efficient dust removal. In addition, the laser cleaning machine also has rust prevention and rust removal functions.
Product Specification | ||||
Mode | OTQX-1000 | OTQX-1500 | OTQX-2000 | OTQX-3000 |
Laser source power | 1000w | 1500w | 2000w | 3000w |
Laser wavelength | 1080±10mm | |||
Laser type | Continuous/Modulation | |||
Maximum Modulation Frequency | 20khz | |||
Cable length | 10m(15m can be customized)20m(Standard for BLC3000 | |||
Scan Width | 10-160mm | |||
Power configuration | AC 220V±10% | AC 380V±7% | ||
6KW | 8KW | 10KW | 13KW | |
Cooling method | Water cooling (Medium:Deionized water,distilled water or purified water ) | |||
Machine Dimension | 845*460*605mm | 905*480*630mm | 1240*584*1148m m | |
Packing Dimension | 1120*565*1050mm | 1430*720*1220m m | ||
Net weight | 106kg | 113kg | 137kg | 235kg |
Gross Weight | 138kg | 145kg | 169kg | 280kg |
Water tank Capacity | 16L(14-15L of water to be added |
The advantages of handheld laser cleaning machines are as follows:
1. Non-contact cleaning: The laser cleaning machine irradiates the
surface of the object with a high-energy laser beam, which can
quickly and effectively remove various pollutants without causing
any damage to the object itself. This non-contact cleaning method
can effectively avoid scratches, scratches and other problems that
may occur in traditional cleaning methods.
2. Efficient and environmentally friendly: The laser cleaning
machine does not need to use any chemical reagents or cleaning
agents during operation, which can effectively reduce environmental
pollution and harm to the human body. At the same time, the laser
cleaning machine does not produce noise or waste, and is an
efficient and environmentally friendly cleaning method.
3. Wide range of applications: Laser cleaning machines can be used
for surface cleaning of various materials, such as metal, glass,
ceramics, plastics, etc. This wide range of applications makes the
laser cleaning machine a universal cleaning tool that can meet a
variety of different cleaning needs.
4. Precise control: The laser cleaning machine can achieve precise
control of the cleaning process by accurately controlling
parameters such as the power, frequency, and scanning speed of the
laser beam. This precise control method can effectively avoid
damage to areas that do not need to be cleaned, and can also
improve the efficiency and effectiveness of cleaning.
5. Easy to operate and maintain: The laser cleaning machine is
simple and convenient to operate, and ordinary personnel can use it
skillfully after simple training. At the same time, the laser
cleaning machine has a simple structure and small size, making it
easy to move and carry, as well as for maintenance and repair.
